Name: Alleys

Display Field: STREET

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Powell Bill Alleys are alleys which the City of Wilmington legally maintain, and recieves reimbursement from the State of North Carolina for maintaining these designated roads. No Private or State maintained alleys are reimbursable, but are shown in the layers. Powell Road segments must be in a designated city ROW. </SPAN></P><P><SPAN /></P></DIV></DIV></DIV>

Service Item Id: 56dcb9d36d1a4c309885ad587918a620

Copyright Text: City of Wilmington Engineering

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: true

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2316989.471750632
YMin: 109892.45757488906
XMax: 2371037.7081421316
YMax: 219860.5840948969
Spatial Reference: 103122  (6543)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 3
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: [STREET] CONCAT " " CONCAT [STRTYPE]
Use Coded Values: true
Symbol:
Color: [255, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: baseline
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 7
Font Family: Arial
Font Style: italic
Font Weight: normal
Font Decoration: none

Min. Scale: 8000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• STREET ( type: esriFieldTypeString, alias: STREET, length: 25 )
• STRTYPE ( type: esriFieldTypeString, alias: STRTYPE, length: 3 )
• STRDIR ( type: esriFieldTypeString, alias: STRDIR, length: 2 )
• POWELLID ( type: esriFieldTypeSmallInteger, alias: POWELLID )
• POWELL ( type: esriFieldTypeSmallInteger, alias: POWELL , Coded Values: [1: State Maintained] , [6: City Maintained - not included in Powell report] , [7: City Maintained - paved > 16' wide] , ...7 more... )
• PDATE ( type: esriFieldTypeDate, alias: PDATE, length: 8 )
• TOFROM ( type: esriFieldTypeString, alias: TOFROM, length: 75 )
• SURFACE ( type: esriFieldTypeString, alias: SURFACE, length: 10 )
• ROWWIDTH ( type: esriFieldTypeSmallInteger, alias: ROWWIDTH )
• PAVEWIDTH ( type: esriFieldTypeSmallInteger, alias: PAVEWIDTH )
• USEABLEWIDTH ( type: esriFieldTypeSmallInteger, alias: USEABLEWIDTH )
• CANOPYHGHT ( type: esriFieldTypeSmallInteger, alias: CANOPYHGHT )
• OWNER ( type: esriFieldTypeString, alias: OWNER, length: 10 )
• DEPTUSE ( type: esriFieldTypeString, alias: DEPTUSE, length: 20 )
• VEGMAINT ( type: esriFieldTypeString, alias: VEGMAINT, length: 10 )
• VEGTYPE ( type: esriFieldTypeString, alias: VEGTYPE, length: 10 )
• VEGTYPEMAINT ( type: esriFieldTypeString, alias: VEGTYPEMAINT, length: 10 )
• VEGMAINTDATE ( type: esriFieldTypeDate, alias: VEGMAINTDATE, length: 8 )
• RDMAINT ( type: esriFieldTypeString, alias: RDMAINT, length: 50 )
• RDMAINTDATE ( type: esriFieldTypeDate, alias: RDMAINTDATE, length: 8 )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 100 )
• SWMHazard ( type: esriFieldTypeString, alias: SWMHazard, length: 20 )
• MAPBOOK ( type: esriFieldTypeSmallInteger, alias: MAPBOOK )
• MAPPAGE ( type: esriFieldTypeSmallInteger, alias: MAPPAGE )
• DEEDBOOK ( type: esriFieldTypeSmallInteger, alias: DEEDBOOK )
• DEEDPAGE ( type: esriFieldTypeSmallInteger, alias: DEEDPAGE )
• RODMAPTYPE ( type: esriFieldTypeString, alias: RODMAPTYPE, length: 50 , Coded Values: [plat: Plat map] , [cond: Condo map] )
• NHCMAPURL ( type: esriFieldTypeString, alias: NHCMAPURL, length: 300 )
• CONTACTNAME ( type: esriFieldTypeString, alias: CONTACTNAME, length: 50 )
• CONTACTPHONE ( type: esriFieldTypeString, alias: CONTACTPHONE, length: 20 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• CBD ( type: esriFieldTypeString, alias: CBD, length: 5 )
• SHAPE.len ( type: esriFieldTypeDouble, alias: SHAPE.len )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
